Focus Range

NDAA 4MP H.265 IP Eyeball Cam 2.8-12mm V/F AF IR Gunmetal Gr

PWIP4NEBVAFG
Price on sign in

In stock

Product description

The Genie PWIP4NEBVAFG is a 4MP IP IR eyeball camera with a 2.8-12mm auto focus lens. The camera also features up to 50m IR night view distance as well as being IP67. Finished in a Gunmetal Grey Housing.


Key features

  • NDAA compliant
  • 4MP (2560 x 1440) H.265 coding
  • Maximum resolution: 2560 x 1440
  • ICR auto switch, true day / night, ROI coding
  • 3D DNR, digital WDR, HLC, BLC, defog
  • 30~50m IR night view distance
  • DC12V / PoE power supply
  • 1Channel built-in MIC
  • IP67 ingress protection
  • Supports remote monitoring by smart phones and tablet PCs with iOS and Android OS

  • Supports three streams
  • Intelligent analytics : Object removal detection, abnormal video signal detection,
    line crossing detection and region intrusion detection
  • Onvif compliant

Specification

Camera Image Sensor

1 / 3 “CMOS

Camera Image Size

2560 x 1440

Camera Electronic Shutter

1 / 2 s ~ 1 / 100000 s

Camera Iris Type

Fixed Iris

Camera Minimum Illumination

0.005 lux @F1.6, AGC ON; 0 lux with IR

Camera Lens

2.8~12mm@ F1.4
Horizontal : 92 °~31 °; Vertical: 48 °~17.2°;
Diagonal: 112 °~ 35.6 °
Manual or motorized

Camera Lens Mount

Φ14

Camera Wide Dynamic Range

120dB

Camera BLC

Yes

Camera HLC

Yes

Camera Defog

Yes

Camera Digital NR

Yes

Camera Angle Adjustment

Pan: 0°~360°, Tilt: 0°~80°,
Rotation: 0°~360°

Image Video Compression

Main stream: H.265
Sub stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264 / MJPEG / H.264

Image H.265 Compression Standard

Main Profile @ Level 4.1 High Tier

Image Resolution

4MP (2560 x 1440),
3MP (2304 x 1296),
1080p (1920 x 1080),
720p (1280 x 720),
D1, CIF, 480 x 240

Image Main Stream

60Hz : 4MP / 3MP / 1080p (1~30fps)
50Hz : 4MP / 3MP / 1080p (1~25fps)

Image Sub Stream

60Hz: 720P/D1/CIF (1~30fps);
50Hz: 720P/D1/CIF (1~25fps)

Image Third Stream

60Hz : D1 / CIF / 480 x 240 (1~30fps)
50Hz: D1 / CIF/ 480 x 240 (1~25fps)

Image Bit Rate

64 Kbps ~ 8 Mbps

Image Bit Rate Type

VBR / CBR

Image Settings

ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness,
Image Mirror, Image Flip, NR, etc. adjustable through client software or web browser

Image ROI

Each ROI to be configured separately

Remote Monitoring

Web browsing, CMS remote control

Online Connection

Supports simultaneous monitoring for up to 3 users.
Supports multi-stream real time transmission

Network Protocol

UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP,
802.1x, UPnP, HTTP, HTTPs, QoS

Interface Protocol

Onvif compatible

Intelligent Analytics

Region intrusion detection, Object removal detection,
Abnormal video detection, Line crossing detection

Storage

Network remote storage; micro SD card storage

Smart Alarm

Motion detection

General Function

Watermark, IP address filtering, video mask, heartbeat, password protection

PoE

Yes

Interface Network

RJ45

Interface Video Output

No

Interface Audio

1Channel audio input; 1Channel built-in MIC

Interface Storage

Built-in micro SD card slot, up to 256GB

Interface Hardware Reset

Yes

Ingress Protection

IP67

Power Supply

DC12V / PoE

Power Consumption

< 8W

Operating Environment

– 30 °C ~ 60°C (-22°F~140°F)
Humidity: Less than 95% (Non-condensing)

Dimensions

111.5 x 99.6 mm

Weight

Approximately 0.64Kg
