H.265 8 Channel NVR 5MP 30fps 1 HDD HDMI/VGA 8xPOE 8xAudio Capable 1xHDD Bay
In stock
Product description
The Genie ‘Optimised’ WONVR18P5 PoE Network video recorders offer 8 channel recording of up to 5 Mega Pixels on every channel. The WONVR18P5 NVR supports 8 channel simultaneous playback with 8 ports of PoE.
Key features
- Supports 8 channel 5MP, 4MP, 3MP, 1080p, 960p and 720p IP input
- Adopt standard H.265 and H.264 high profile compression format to get high quality video at much lower bit rate
- Intuitive and user friendly Graphic User Interface (GUI), Windows style operation by mouse
- Multi-mode recording: Manual / Timer / Motion / Sensor
- Search : Time slice, time, event (Manual, sensor, motion), Tag search
- Express and flexible backup via USB, network etc.
- 8 channel simultaneous playback
- Pentaplex : Preview, Record, Playback, Backup and Remote Access
- DHCP, DDNS, PPPoE network protocol and CMS supported
- Remote control via IE or CMS : Preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously
- Authorisation management, log view and device status view
- 1080p HD output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QR code scanning by mobile phone and iPad
- Powerful smart phone & iPad surveillance with iOS and Android OS
Specification
- Weight
- 1.14 kg
- OS
-
Embedded Linux
- Network Access Format
-
5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps
- Compression
-
Standard H.265, H.264
- Network Input
-
8 CH IPC audio input
- Audio Local Output
-
No (HDMI supports the audio output)
- Record Stream
-
Dual stream recording
- Resolution
-
5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps
- Mode
-
Manual, Timer, Motion, Sensor
- Mobile OS
-
iOS, Android
- Storage
-
HDD: SATA x 1, up to 6TB per HDD
- Simultaneous Playback
-
8 CH max.
- Search
-
Time slice / Time / Event / Tag search
- Smart Search
-
Highlighted colour to display the camera record in a certain period of time, different colours refer to different record events
- Function
-
Play, Pause, FF, FB, Digital zoom, etc
- Network Interface
-
RJ45 100 Mbps x 1
- Protocol
-
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
- IP Input Access / Transfer Bandwidth
-
56Mbps / 56Mbps
- Alarm Mode
-
Manual, Sensor, Motion, Exception
- Input
-
No
- Output
-
No
- Triggering
-
Record, Snap, Preset, E-mail, etc.
- Remote Monitoring
-
Immix: Compatible with Immix via RTSP only (2-way audio not supported)
Sentinel: Yes, Firmware 1.1.0 or later
- Local Backup
-
USB stick, USB mobile HDD
- Network Backup
-
Yes
- USB Port
-
USB 2.0 x 2
- Remote Controller
-
Optional
- Power Supply
-
DC12V, 1.5A
- Consumption
-
<6W (Without HDD)
- Working Environment
-
Temperature: -10°C – 50°C,
Humidity: 10% – 90% - Dimensions
-
255 x 234 x 42 mm
