NDAA 5MP H.265 Triple Stream Junction Box Covert Camera Pinhole PoE
In stock
Product description
The Genie GIP5NJB is a 5MP triple stream, NDAA compliant conical pinhole camera housed in a wall mount junction box. The unit is suitable for discreet and covert operations.
Key features
- 5MP resolution
- 1/ 2.8” 5MP progressive CMOS sensor
- H.265 / MJPEG triple streaming
- Minimum illumination: 0.1 Lux (Colour)
- WDR, D&N, AGC, BLC, HLC, DNR, Sens-Up
- 32mm x 32mm PCB (video only)
- Motion detection / privacy zone
- NDAA compliant
Specification
- Weight
- 0.15 kg
- Image Sensor
-
Sony STARVIS 1/2.8” 5.69 Megapixel Image Sensor
- Diagonal Size
-
6.46mm (Type 1/2.8)
- Scan Method
-
Progressive Scan
- Total Pixels
-
2704 (H) x 2104 (V), 5.69 Megapixels
- Effective Pixels
-
2616 (H) x 1964 (V), 5.14 Megapixels
- Day & Night
-
Auto / Day (Colour) / Night (BW), ICR Control
- Privacy Area
-
16 Programmable Zones, On / Off
- Motion Detection
-
432 Zone, Sensitivity 1 ~ 5 Step, On / Off
- W D R
-
Real WDR On (Adjust) / Off
- D N R
-
2DNR, 3DNR, On (Adjust) / Off
- Defog
-
Detects Fog, On (Adjust) / Off
- S L D C
-
Simple Lens Distortion Correction, On (Adjust) / Off
- Elec. Shutter
-
Auto(1/30 ~ 1/15000), Suppress Rolling, Manual
- Colour Adjust
-
Bright / Contrast / Saturation / Sharp
- White Balance
-
Auto (indoor) / Auto (Outdoor) / User
- OSD Display
-
Text, Date, Time, Event, On / Off
- Image Mirror
-
Normal / Mirror(H) / Flip(V) / Both(HV)
- Power Supply
-
DC12[V] ± 10%, PoE (802.3af)
- Current
-
Max 250[mA]
- Interface
-
RJ45 10/100 Base-T
- Protocol
-
TCP / IP, UDP / IP, RTP, RTS, RTCP, NTP, HTTP, DHCP, FTP, SMTP, DNS, DDNS
- ONVIF
-
Ver19.12
- Simultaneous Access
-
Max. 10 User
- OS
-
Windows 7, 8, 10
- Viewer
-
IE11 or above (Active-X)
- Compress Format
-
H.265 / H.264 / MJPEG
- Resolution
-
2560 x 1920 / 2560 x 1440 / 1920 x 1080 / 1280 x 1024 / 1280 × 960 / 1280 × 720 / 1024 × 768 / 640 × 480 / 320 × 240
- Maximum Frame Rate
-
30fps at all resolutions
- Video Quality
-
H.265 : Bitrate Control
H.264 : Bitrate Control
MJPEG : Quality Level Control - Streaming
-
Triple Stream (Stream 1, 2, 3)
RTP / RTSP, Unicast RTP, Multicast RTP - Operating Temperature
-
0°C ~ +50°C
- Preservation Temperature
-
-10°C ~ +60°C
- Operating Humidity
-
0~90%
- Dimensions
-
32mm (W) X 32mm (H) X 20.00mm (D)
