2CH AHD/CVI/TVI /CVBS Signal Video multiplexer over one coax

GHD102
Price on sign in

In stock

Product description

The Genie GHD102 uses FDM compression modulation technology on the transmitter and allows 2 channels of CVI / AHD / TVI / CVBS camera signals to be compressed and converted into a digital signal which is then transmitted using a single coaxial cable. The receiver then decompresses and re-converts the signal back into 2 separate video channels allowing you to connect to a compatible DVR (CVI / TVI / AHD / CVBS) or video matrix. This product automatically adjusts for transmission distances from 0-200 m. The maximum transmission distance supported depends greatly on the quality of the coax cable being used.


Key features

  • Designed with minimum installation requirement
  • 2x separate video channels down 1 coaxial cable
  • Real-time images
  • Simple plug and play operation
  • Built-in static protection circuit
  • Ideal for utilising existing cables already installed
  • Supports coaxial video line 75-3, 75-5, RG59 etc.
  • FDM technology is easy for multi-channel signal transmission in 1 coaxial cable with minimum delay and interference

Specification

Weight
0.6 kg
Compatible Mode

AHD / CVI / TVI / CVBS

Supported Pixels

TVI : 720p / 1080p / 3MP
AHD : 720p / 960p / 1080p
CVI : 720p / 960p / 1080p
CVBS

Interface

BNC Port

Power Supply Input

DC12V x2 (Not Supplied)

Transmission Distance

0-200m (Adaptive)

Operating Temperature

-30°C – 50°C

Material

High quality Aluminium Alloy

Dimensions

64 x 43 x 23 mm

Weight

67.5g (Each)
