AHD 1080P 4″ External PTZ Camera 360′ 18x Optical IR’s 12V DC c/w Wall Bracket
Out of stock
Product description
The Genie GAHD18IRPTZ is an AHD 18x optical zoom external 360° PTZ camera. With 360° endless pan range and 0-90° tilt range, the camera is suited to a wide range of environments.
Key features
- 18x optical zoom
- IP66 ingress protection
- 60m IR distance (in ideal conditions)
- RS485 PTZ control
- Supports auto iris, electronic shutter, automatic white balance, backlight compensation
- 6 piece infrared lights
- Supports 220 presets, 8 patrols, 4 patterns
- 360° endless pan range and 0-90° tilt range
- PELCO-D/P communication protocols
- NDAA compliant
Specification
- Weight
- 1.38 kg
- Image Sensor
-
1/2.8” Sony CMOS
- Image
-
Flip / Mirror
- Scanning System
-
Progressive scanning
- Resolution
-
1920 x 1080
- Electronic Shutter
-
1/25 ~ 1/10,000s
- Minimum Illumination
-
Colour: 0.05 Lux / F2,
B&W: 0.005 Lux / F2, 0 Lux (IR) - Optical Zoom
-
18x
- S / N Ratio
-
> 50dB (AGC Off)
- Exposure Mode
-
Auto
- 2D DNR
-
Supports
- BLC
-
On / Off
- Synchronous
-
Internal synchronisation
- Day / Night Mode
-
Supports IR-CUT colour to black
- Focus Mode
-
Auto / Manual
- Gain Control
-
Auto / Manual
- Lens Initialisation
-
Built-in
- Focus Range
-
4.7 ~ 84.6mm (Wide-Tele)
- Pan Angle
-
54.8° ~ 3.4° (Wide – Tele)
- IR Distance
-
60m (in ideal conditions)
- IR Angle
-
3 angle adjustable with zoom in/out
- Pan Speed
-
0.6° ~ 180°/S
- Tilt Speed
-
3.5° ~ 30°/S
- Tilt Range
-
0° ~ 90°, Auto flip 180°
- Manual Speed
-
High / Middle / Low for adjustable
- Proportional Zoom
-
Supports
- Preset
-
220
- Patrol
-
4, each patrol can add 32 preset
- Pattern
-
4, total record time more than 10mins
- A.B Preset Scan
-
Supports
- Park Function
-
Supports, can select preset, patrol, pattern, A.B scan, pan auto running
- BNC Output
-
AHD / CVI / TVI / CVBS (1Vp-p 75Ω, PAL / NTSC, BNC
- Communication Protocols
-
PELCO-D/P
- ID
-
1-255
- Baud Rate (RS485)
-
2400/4800/9600bps/auto identify
- Ingress Protection
-
IP66
- Lightning Protection
-
TVS3000V lightning protection, surge protection and voltage transient protection
- Power Supply
-
DC12V/2A
- Power Consumption
-
Max. 20W (Not including the heat)
- Working Environment
-
-20°C~-60°C, ≤90%RH (Frostless)
- Dimensions
-
208 x 251.1 x 136.1 mm
- Weight
-
4 Kg
