NDAA H.265 8MP@15fps 16 Channel 5in1 DVR 16xIP HDMI/CVBS Out 2x HDD Bay
In stock
Product description
The Genie WAHDN8162 is a DVR that supports 16 channel 8MP, 5MP, 4MP, 3MP, 1080p, 720p and WD1 analogue and IP video input simultaneously. It adopts the standard H.265 high profile compression format and supports 16 channel video input, 1 channel audio input and simultaneous 16 channel playback.
Key features
- Supports 16 channel TVI / AHD / CVI 8MP, 5MP, 4MP, 3MP, 1080p, 720p and WD1 video input
- Supports 8 channel 8MP, 5MP, 4MP, 3MP, 1080p, 720p and WD1 IP input by default
- Standard H.265 high profile compression format to get high-quality video at much lower bit rate
-
Intuitive and user-friendly Graphics User
Interface (GUI window style operation by mouse) - Pentaplex: Preview, Record, Playback, Backup and Remote access
- HDMI 4K output, true high resolution display
-
Multi-mode recording: Manual / Timer /
Motion / Smart Event. Playback : 16 channel simultaneous playback - Search: Time Slice, Time, Event, Tag and Smart Search
-
Express and flexible backup via USB and
Network - DHCP, DDNS, PPPoE Network protocol
-
Remote control via IE or CMS : Preview,
Playback, Backup, PTZ and Configuration -
Authorisation management, log review and
device status review - Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Simultaneous multi-user online
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QR Code scanning by mobile phones and tablets
- Powerful mobile surveillance by smart phones with iOS and Android OS
Specification
- Weight
- 3 kg
- Analogue Video Input
BNC x16
BNC interface (1.0Vp-p, 75Ω)
TVI / AHD / CVI : 4K@15fps, 5MP @ 20fps, 4MP / 3MP / 1080p / 720p / WD1 @ 30fps (Live)- IP Video Input
8CH (Up to 16CH)
Up to 8MP @ 30fps- Total Input
24CH
- Two-Way Audio
Take up channel one audio input
- Compression
G.711(U/A)
- Resolution
4K / 4K Lite / 5MP / 5MP Lite / 4MP / 4MP Lite / 3MP / 1080p / 720p / WD1 / D1
- Frame Rate
Analogue Channel:
4K @ 8fps (PAL / NTSC) 4K Lite @ 12fps/15fps (PAL / NTSC) 5MP @ 12fps (PAL / NTSC) 5MP Lite @ 20fps (PAL / NTSC) 4MP/3MP @ 12fps/15fps (PAL / NTSC) 4MP Lite/1080p/720p/WD1/D1 @ 25fps (PAL) / 30fps (NTSC)
IP Channel: 8MP @ 25fps / 30fps (PAL / NTSC)- Bit Rate
32Kbps ~ 5Mbps
- OS
iOS, Android
- HDD
SATA x2, Up to 8TB per HDD
- Playback
16CH
- Search
Time Slice / Time / Event / Tag Search
- Smart Search
Highlight colours to display the camera record in a certain period of time, different colours refer to different record events
- Function
Play, Pause, FF, FB, Digital Zoom, etc.
- Mode
Manual, Motion, Exception, Smart Event
- Input
No
- Output
No
- Interface
RJ45 1000Mbps x 1
- Protocol
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP, ONVIF
- Incoming Bandwidth
32Mbps
- Outgoing Bandwidth
96Mbps
- Immix
Compatible with Immix via RTSP only (2-way audio not supported)
- Sentinel
Yes, Firmware 1.1.0 or later
- Local Backup
U disk, USB mobile HDD
- Network Backup
Yes
- RS485
Yes (Half-duplex), Connect to PTZ or Keyboard
- USB
USB 2.0 x 2
- Remote Controller
Optional
- Power Supply
DC12V / 4A
- Consumption
≤30W (Without HDD)
- Working Environment
-10~50°C, 10%~90% (Humidity)
- Dimensions
380 x 268 x 45 mm
