NDAA 5MP H.265 IP Dual Eyeball Camera, True and Thermal Image 4mm / 3.2mm Thermal
In stock
Product description
The Genie WIPDT5NEB is a 5MP Dual Camera. True And Thermal Image With AI Heat Source Alarm Trigger And Fire Detection.
Intelligent analytics: intrusion detection (human/motor vehicle classification), Line crossing detection (human/motor vehicle classification), Scene change detection, video exception detection, Target counting(human/vehicle/non-motor vehicle classification), Face detection, Face capture
Key features
- Resolution: 256×192
- Temperature range: -20°C~150°C
-
Multi-palette: white hot, black hot, iron oxide red, etc
- Sound and light warning, temperature exception alarm, fire detection
-
Supports temperature overlay on video stream
-
Intelligent analytics: intrusion detection (human/motor vehicle classification),
Line crossing detection (human/motor vehicle classification),
Scene change detection, video exception detection,
Target counting(human/vehicle/non-motor vehicle classification),
Face detection, Face capture - Supports dual image fusion
- 5MP ( 2592 × 1944 ) @30 fps
- ICR auto switch, true day/night vision
- 20~30m IR night view distance
-
3D DNR, true WDR(120dB), HLC, BLC, Smart IR, distortion image correction, ROI etc.
Specification
- Thermal Module Detector Type
-
12μm 256×192
- Thermal Module Response Waveband
-
8μm-14μm
- Thermal Module NETD
-
≤50mK(@25°C, F#=1.0)
- Thermal Module Iris Type
-
Fixed Iris
- Thermal Module Field of View(H×V)
-
56°×42.2°
- Thermal Module Min. Focusing Distance
-
0.5 m
- Thermal Module Colour Palettes
-
Black hot, White hot, iron oxide red, etc
- Thermal Module DRI Distance Human (0.75m)
-
Detection: 133m(436ft) Recognition: 33m(108ft) Identification:17m(56ft)
- Thermal Module DRI Distance Vehicle (2.3m)
-
Detection: 409m (1342ft) Recognition: 102m(335ft) Identification:51m(167ft)
- Image Video Compression
-
H.265 / H.264 / MJPEG
- Image H.264 Compression Standard
-
Baseline Profile / Main Profile / High Profile
- Image Bit Rate Type
-
VBR/CBR
- Image Bit Rate
-
128Kbps~ 8Mbps
- Image Resolution
-
Optical: 5MP ( 2592 × 1944 ), 4MP ( 2592 × 1520 ), 2K ( 2560 × 1440 ), 3MP ( 2304 × 1296 ),
1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240
Thermal: 720P ( 1280 × 720 ), D1, CIF, 480 x 240 - Image Main Stream
-
Optical: 60Hz:5MP/4MP/2K/3MP/1080P/720P(1~30fps);
50Hz: 5MP/4MP/2K/3MP/1080P/720P (1~25fps)
Thermal: 256×192(the resolution of output image is 720P/D1/CIF/480×240) (1~25fps) - Image Sub Stream
-
Optical: 60Hz: 720P/D1/CIF (1~30fps); 50Hz: 720P/D1/CIF (1~25fps)
- Image Third Stream
-
Optical: 60Hz: D1/CIF/480×240(1~30fps); 50Hz: D1/CIF/480×240(1~25fps)
- Image : Dual Image Fusion
-
Yes
- Image Temperature Overlay
-
Temperature can be overlaid on video stream
- Image Settings
-
ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic, Sharpness, NR, etc.
adjustable through client software or web browser - Image : Audio Compression
-
G711A/U
- Image : ROI
-
8 regions; each ROI to be configured separately
- Functions : Temperature Range
-
-20°C~150°C (-4°F~302°F)
- Functions : Temperature Accuracy
-
±8°C
- Functions : Temperature Alarm
-
Over temperature alarm, low temperature alarm
- Functions : Temperature Measurement
-
10 rules in total (Point: up to 10; Line: up to 10; Area: up to 10)
- Functions : Fire Detection
-
Dynamic fire detection, up to 10 fire points detectable
- Functions : Remote Monitoring
-
Web browser/NVMS2.X/Mobile APP
- Functions : Online Connection
-
Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission
- Functions : Network Protocol
-
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS,
SMTP, FTP, SNMP,HTTP, 802.1x, UPnP, HTTPs, QoS - Functions : Interface Protocol
-
ONVIF
- Functions : Storage
-
Network remote storage; micro SD card storage
- Functions : Smart Alarm
-
Motion detection, SD card error, SD card full, IP address conflict, Cable connection
- Functions : Intelligent Analytics
-
Optical: intrusion detection/line crossing detection
(human/motor vehicle/non-motor vehicle classification), scene change detection,
video exception detection, target counting(human/motor vehicle/non-motor vehicle classification)
face detection, face capture.
Thermal: fire detection, temperature exception alarm, intrusion detection/line crossing detection
(human/motor vehicle classification)
AI function can be enabled simultaneously on thermal and optical channels - Functions : General Functions
-
Watermark, IP address filtering, video mask, heartbeat, password protection,
image distortion correction - Functions : Sound & Light Warning
-
White light flashing alarm and sound alarm supported
- Functions : PoE
-
Yes , IEEE802.3 af, class0
- Functions : IR Distance
-
20~ 30m
- Functions : Protection Grade
-
IP66
- Visible Light Module : Image Sensor
-
1/ 2.7” CMOS
- Visible Light Module : Image Size
-
2592 × 1944
- Visible Light Module : Electronic Shutter
-
1/3 s ~ 1 / 100000 s
- Visible Light Module : Iris Type
-
Fixed Iris
- Visible Light Module : Min. Illumination
-
0.02 [email protected],AGC ON; 0 lux with IR
0.03 [email protected],AGC ON; 0 lux with IR - Visible Light Module : Lens
- Visible Light Module : Field of View(H×V)
-
81°×56.7°
- Visible Light Module : Wide Dynamic Range
-
120dB
- Visible Light Module : BLC
-
Yes
- Visible Light Module : HLC
-
Yes
- Visible Light Module : Defog
-
Yes
- Visible Light Module : Digital NR
-
2D/3D DNR
- Interfaces : Network
-
RJ 45
- Interfaces : Video Output
-
No
- Interfaces : Audio
-
1CH 3.5mm MIC/LIN in audio input;
1CH built-in MIC; 1CH built-in speaker - Interfaces : Storage
-
Built-in micro SD card slot; up to 256GB
- Interfaces : Reset
-
Yes
- Interfaces : RS485
-
No
- Interfaces : Alarm
-
1 Channel alarm input; 1 Channel alarm output
- Power Supply
-
DC12V / PoE
- Power Consumption
-
< 9W
- Operating Environment
-
Humidity: less than 95 % (non-condensing) -30 °C ~ 60 °C (-22°F~140°F)
- Certificate
-
CE, FCC
- Environment Protection
-
Complies with Directive EU RoHS, WEEE(2012/19/EU) , directive 94/62/EC
and REACH(EC1907/2006) - Dimensions ( mm )
-
Ø111.5 × 99.6
- Weight ( net )
-
Approx. 0.68KG
- Installation
-
Ceiling mounting; Wall mounting
